VBar to NM Circumnavigation RPO Sequence

The VBar To NM Circumnavigation RPO sequence initiates an NMC from an initial VBar position. The current initial VBar position must be at least 10 meters from the target, and all relative motion must be zero. The NMC has an option to have a cross-track component when it crosses the RBar, but the other parameters are dictated by being initially on the VBar.

If the initial position is not on the VBar, the sequence issues an error message and terminates.

The following picture shows an NMC initiated from -500 meters on the VBar and then propagated for one revolution.

Watch the following video to learn more about the RPO sequence on this page.

Sequence parameters

Option	Description
CrossTrack	Enter, in distance units, the desired cross-track offset when crossing the RBar.
Engine_Name	Enter, as a string, the name of the finite maneuver engine model.
Maneuver_Type	Select the type of maneuver, "Impulsive" or "Finite," from the drop-down list.
WhoAmI	Enter, as a string, the name of the current satellite.
