Satellite Tracker

public struct ViewingOpportunity
{
    public double StartJulianDateUtc;
    public double EndJulianDateUtc;
    public double ApproachAzimuth;
    public double DepartureAzimuth;
}

[WebMethod(Description = "Find the times during which a satellite is viewable from a specified location.")]
public ViewingOpportunity[] GetViewingOpportunities(string tleString,
                                                    double startSearchJulianDateUtc, double endSearchJulianDateUtc,
                                                    double viewingLongitudeDeg, double viewingLatitudeDeg, double minViewableElevationAngleDeg)
{

UserInput input = new UserInput
{
    Tle = tleString,
    Longitude = viewingLongitudeDeg,
    Latitude = viewingLatitudeDeg,
    MinimumElevationAngle = minViewableElevationAngleDeg
};
AccessQuery access = input.CreateAccessQuery(out satellite, out facility);

public AccessQuery CreateAccessQuery(out Platform satellite, out Platform facility)
{
    // Create an SGP4 propagator to propagate the TLE.
    Sgp4Propagator propagator = new Sgp4Propagator(new TwoLineElementSet(Tle));
    satellite = new Platform();
    facility = new Platform();

    // Create a Point representing the position as reported by the propagator. The propagator
    // produces raw ephemeris, while the Point enables the results of propagation to work with
    // the GeometryTransformer in order to observe the ephemeris in different reference frames.
    satellite.LocationPoint = propagator.CreatePoint();
    satellite.OrientationAxes = Axes.Root;

    // Create a facility at the viewing location. The longitude and latitude of the facility's
    // location are specified using radians, so convert degrees to radians.
    facility.LocationPoint = new PointCartographic(
        CentralBodiesFacet.GetFromContext().Earth,
        new Cartographic(
            Trig.DegreesToRadians(Longitude),
            Trig.DegreesToRadians(Latitude),
            0.0));
    facility.OrientationAxes = Axes.Root;

    // Create an Access constraint requiring that the satellite be above a particular elevation
    // angle relative to the local horizontal plane of the facility.
    ElevationAngleConstraint elevationAngleConstraint = new ElevationAngleConstraint();
    elevationAngleConstraint.MinimumValue = Trig.DegreesToRadians(MinimumElevationAngle);
    elevationAngleConstraint.MaximumValue = Constants.HalfPi;

    // Create the link between the two platforms, we will ignore time delay affects from
    // speed of light and make an instantaneous link. It does not matter which is the
    // transmitter and which is the receiver, but the elevation angle constraint must be
    // applied to the facility. In this case we will assume the facility is the receiver.
    LinkInstantaneous link = new LinkInstantaneous(satellite, facility);
    elevationAngleConstraint.ConstrainedLink = link;
    elevationAngleConstraint.ConstrainedLinkEnd = LinkRole.Receiver;

    return elevationAngleConstraint;
}

public void Compute()
{
    // Obtain the Earth for the current context (thread).
    EarthCentralBody earth = CentralBodiesFacet.GetFromContext().Earth;

    // Get an evaluator that tells us the location of the satellite's point
    // in the Earth Inertial reference frame. We wrap this up in a using
    // block so that that evaluator is automatically disposed when we're done.
    // Then, get another evaluator, this one to tell us the location of the satellite
    // in longitude, latitude, and altitude coordinates relative to the Earth.
    using (PointEvaluator satelliteInInertialEvaluator = GeometryTransformer.ObservePoint(m_satellite.LocationPoint, earth.InertialFrame))
    using (MotionEvaluator<Cartographic> satelliteInCartographicEvaluator = earth.ObserveCartographicPoint(m_satellite.LocationPoint))
    {
        // Tell derived classes that we're starting computation.
        BeginCompute();

        // If there are no highlighted intervals, or if we're starting before the
        // first one, then the ground track starts off non-highlighted.
        if (Intervals.Count == 0 || GroundTrackInterval.Start < Intervals[0].Start)
        {
            SetHighlighted(false);
        }
        else
        {
            SetHighlighted(true);
        }

        // the index of the next interval in Intervals watch for.
        int nextInterval = 0;

        // true if we're looking for the start of the interval indicated by
        // nextInterval, false if we're looking for the end of it.
        bool lookingForStart = true;

        // Loop over all of the ground track dates based on GroundTrackInterval
        // and TimeStep. Use TimeGenerator as a convenient way to enumerate
        // these dates.
        foreach (JulianDate date in TimeGenerator.FromInterval(GroundTrackInterval.Start, GroundTrackInterval.Stop, TimeStep))
        {
            // Find the interval (or space between intervals) containing this date.
            // We may need to generate additional ground track points as we move
            // through the intervals in order to accurately represent that transition
            // from highlighted to non-highlighted (or vice-versa).
            bool keepMoving = true;
            while (keepMoving && nextInterval < Intervals.Count)
            {
                // Start off assuming we found the correct interval
                // (or space between intervals).
                keepMoving = false;

                // If we're looking for the start of an interval and the current
                // date is on or after the start of the 'nextInterval'...
                if (lookingForStart && date >= Intervals[nextInterval].Start)
                {
                    // Add a final non-highlighted point at the start of the
                    // highlighted interval.
                    AddPointInternal(Intervals[nextInterval].Start, satelliteInInertialEvaluator, satelliteInCartographicEvaluator);

                    // Switch to highlighted.
                    SetHighlighted(true);

                    // Add a highlighted point at the start of the highlighted
                    // interval, but only if the current 'date' and the start
                    // of the interval are not identical. If they are, the
                    // necessary point will be added below so adding it here, too,
                    // would be redundant.
                    if (date > Intervals[nextInterval].Start)
                    {
                        AddPointInternal(Intervals[nextInterval].Start, satelliteInInertialEvaluator, satelliteInCartographicEvaluator);
                    }

                    // Now we're looking for the end of this interval.
                    lookingForStart = false;
                }

                // If we're looking for the end of an interval and the current
                // date is on or after the end of the 'nextInterval'...
                if (!lookingForStart && date >= Intervals[nextInterval].Stop)
                {
                    // Add a final highlighted point at the end of the
                    // highlighted interval.
                    AddPointInternal(Intervals[nextInterval].Stop, satelliteInInertialEvaluator, satelliteInCartographicEvaluator);

                    // Switch to non-highlighted.
                    SetHighlighted(false);

                    // Add a non-highlighted point at the end of the highlighted
                    // interval, but only if the current 'date' and the end
                    // of the interval are not identical. If they are, the
                    // necessary point will be added below so adding it here, too,
                    // would be redundant.
                    if (date > Intervals[nextInterval].Stop)
                    {
                        AddPointInternal(Intervals[nextInterval].Stop, satelliteInInertialEvaluator, satelliteInCartographicEvaluator);
                    }

                    // Now we're looking for the start of the next interval.
                    lookingForStart = true;
                    ++nextInterval;
                }
            }

            // Add the current ground track point.
            AddPointInternal(date, satelliteInInertialEvaluator, satelliteInCartographicEvaluator);
        }

        // Tell derived classes that we're done computing.
        EndCompute();
    }
}

public static class SatelliteDatabase
{
    /// <summary>
    /// Gets the categories of spacecraft in the database. The categories are the
    /// "missions" in the STK satellite database.
    /// </summary>
    public static ReadOnlyCollection<string> GetCategories()
    {
        // Filter missions and only return the ones that actually contain
        // spacecraft with two-line element sets (TLEs).
        List<string> result = GetDatabase().GetMissions()
                                           .Where(mission => GetSatellitesInCategory(mission).Count > 0)
                                           .ToList();

        // Sort the categories alphabetically.
        result.Sort();

        return result.AsReadOnly();
    }

    /// <summary>
    /// Gets the common names of all spacecraft with TLEs in a particular category.
    /// </summary>
    /// <param name="category">The category (or mission) of the spacecraft.</param>
    /// <returns>A list of spacecraft common names in the category.</returns>
    public static ReadOnlyCollection<string> GetSatellitesInCategory(string category)
    {
        // Build a satellite database query requiring that the Mission field
        // match the requested category.
        StkSatelliteDatabaseQuery query = new StkSatelliteDatabaseQuery
        {
            Mission = new Regex(category)
        };

        // Filter the entries matching the query and add the ones that have
        // two-line element sets (TLEs).
        List<string> result = GetDatabase().GetEntries(query)
                                           .Where(entry => entry.TwoLineElementSet != null)
                                           .Select(entry => entry.CommonName)
                                           .ToList();

        // Sort the spacecraft names alphabetically.
        result.Sort();

        return result.AsReadOnly();
    }

    public static string GetTleString(string category, string satelliteName)
    {
        // Build a satellite database query requiring that the Mission field
        // match the requested category and the CommonName field match the
        // requested satellite name.
        StkSatelliteDatabaseQuery query = new StkSatelliteDatabaseQuery
        {
            Mission = new Regex(category),
            CommonName = new Regex(satelliteName)
        };

        // Filter the entries matching the query and return the first one that
        // has a two-line element set (TLE).
        // Return empty string if no matches, or no matches had TLEs.
        return GetDatabase().GetEntries(query)
                            .Where(entry => entry.TwoLineElementSet != null)
                            .Select(entry => entry.TwoLineElementSet.ToTleString())
                            .FirstOrDefault() ?? "";
    }

    /// <summary>
    /// Gets the STK satellite database instance.
    /// </summary>
    private static StkSatelliteDatabase GetDatabase()
    {
        // Open the satellite database named "stkSatDb" in the "bin/Data/SatelliteDatabase" subdirectory.
        return new StkSatelliteDatabase(HttpContext.Current.Server.MapPath("~/bin/Data/SatelliteDatabase"), "stkSatDb");
    }
}
